MULTIPLANT / AUTOPLANT PRORES for chemical development
Quality by design (QbD), proven accetable range (PAR) driven automated process R&D / chemical development, scale-up and preparative synthesis.
The Chemspeed AUTOPLANT PRORES has been designed for high output experimentation in the development and optimization of pharmaceuticals, agrochemicals, and fine chemicals.
- End-to-end process R&D / chemical development / scale-up
- Organic and inorganic synthesis, reactions under pressure
- Preparative synthesis
- Crystallization
The cutting edge Process Development Workstation technology allows scientists to execute and perform a variety of workflows in a fully automated fashion and truly mimic the final industrial production process. It provides all the flexibility to optimize integrated reaction sequences, even if a complex configuration of reactors and feed vessels is required.
MULTIPLANT / AUTOPLANT PRORES
Each reactor with its own set of conditions - individually controlled tank reactors (reactor volumes 100, 240, 1’000 mL total volume) with precise, continuous feeds:
- Up to 12 / 24 syntheses per run on an AUTOPLANT (incl reaction prep, reaction execution, work-up, analysis), up to 6 per run on a semi-automated MULTIPLANT.
- Easily exchangeable stirrer designs (anchor, twisted blade, gas entrainment stirrers…).
- Powerful mixing for viscosities up to 80 Pa.s at 300 rpm and 30 Pa.s at 900 rpm with an anchor stirrer.
- Flexible and precise continuous feeds.
- Multiple continuous liquid, liquefied gas and / or gas feeds per reactor and additional unlimited overhead access.
- Independent, precise temperature and stirring control in each reactor (e.g. 130°C temperature difference between adjacent reactors, with active cooling >>130°C).
- Internal and / or jacket temperature control.
- Pressure up to 100 bar with corresponding safety installations.
- Parallel high-performance calorimetry and viscosity data.
- PAT interfaces to various in-situ probes, for example: pH, UV-VIS, IR, Raman, PSD, calorimetry.
- Measurement of gas consumption.
- Dean Stark water trap.
- Distillation bridge.
- Vacuum for different purposes: inertization, crystallization, ...
- Extraction, filtration, evaporation, crystallization, distillation.
- Ventilated hood for safety and conditioned (sensitive chemicals, low-temperature) operation.
- AUTOSUITE SOFTWARE - drag & drop experimentation with easy interface (e.g. python custom device) to e.g. LIMS, ELN, data analysis, AI / ML closed loop.
- Optional integrated online benchtop NMR - including but not limited to 80 MHz Fourier RxnLite, NMR device, sample injection port, software with advanced chemical profiling and hardware integration, H / F / C / P / Si / B, 1D and 2D spectra, online data acquisition via flow cell or offline via standard 5 mm sample tubes, permanent magnet - no liquid nitrogen or helium required, 2 Gauss line inside NMR device housing
- Optional integrated online benchtop XRD such as Bruker D6 Phaser, Malvern Aeris, incl. XRD device, sample handover station, software and hardware integration
